Result
You have disassembled the hybrid plug.
Note
The remov
al of contacts deforms the signal unit case; therefore, the disassembled signal unit
case cannot be reused.
Siemens does not recommend that you reuse the disassembled power unit case. Before reusing
the power unit case, check to make sure that there is no deformation or damage.
A.4.2.3 Assembling connectors for 1FL2 motors, shaft heights 48 and 52
Overvie
w
This section o󹪜ers assembly instructions for power and encoder cables of the 1FL2 motors shaft
heights 48 and 52.
Requirement
You have prepared appropriate tools, raw cables, and the Siemens M17 connector.
Appendix
A.4î™ Assembling cables
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 893
