SMAR CD600 Plus - Page 127

Vgejpkecn"Urgekhkecvkqpu"
:09"
Rj{ukecn"Ejctcevgtkuvkeu"
Microprocessor: 80C196, 16 bits
Memory: 4 Mbytes (FLASH) + 64 Kbytes (NVRAM)
Control Cycle: adjustable from 100 to 250 ms
Housing: Carbon steel with superficial electrolithic Blue Bichorome zinc treatment
Color: Brown
Front Panel: Engineering plastic
Circuit Boards: Fiber-glass reinforced Polyester
Front Dimensions: 72 x 144 x 250 mm
Weight: 1.6 kg
Ceeguuqtkgu"
FGUETKRVKQP" EQFG"
Panel spacer 206-0110
Supply cable SC80
Digital Output isolator for CD600 Plus ISD600P
Panel Interface for CD600PLUS ITF-CD-
- Digital output without fuse; 0
- Digital output with fuse for AC; A
- Digital output with fuse for DC. D
Connection cables between CD600PLUS (left) and ITF interface ITF-CDE-
- 0.5 m; 0
- 1 m; 1
- 1.5 m; 2
- 2.0 m; 3
- 2.5 m; 4
- 3.0 m; 5
- 3.5 m; 6
- 4.0 m; 7
- 4.5 m; 8
- 5.0 m. 9
Connection cables between CD600PLUS (right) and ITF interface ITF-CDD-
- 0.5 m; 0
- 1 m; 1
- 1.5 m; 2
- 2.0 m; 3
- 2.5 m; 4
- 3.0 m; 5
- 3.5 m; 6
- 4.0 m; 7
- 4.5 m; 8
- 5.0 m. 9
Urctg"rctvu"
FGUETKRVKQP" RQUKVKQP" EQFG"
Tag Handle 1 206-0101
Front Panel 2 400-0658
Acryllic window 3 206-0105
Scale 4 400-0659
Front Panel PC Board 5 400-0660
Main Board 6 400-0661
Front Panel grounding spring 7 400-0662
Front Panel locking spring 8 400-0663
Controller’s housing 9 400-0664
Fixing clip 10 400-0665
