SMAR CD600 Plus - Page 128

EF822"Rnwu"/""Wugt‚u"Ocpwcn""
:0:"
FGUETKRVKQP" RQUKVKQP" EQFG"
Auxiliary board AC power supply
Auxiliary board DC power supply
11
400-0666
400-0674
Rear panel with filter board (GLL1199) without AC terminal
Rear panel with filter board (GLL1289) without DC terminal
12
400-0667
400-0675
5 way terminal block 13 400-0668
Supply fuse of the AC back panel
Supply fuse of the DC back panel
14
400-0669
400-0676
Terminal board 15 400-0670
Shunt Resistor (250 Ohms) 16 400-0671
10 way terminal block 17 400-0672
11 way terminal block 18 400-0673
Main board with complete front set 1 to 6 400-0677
Complete front set 1 to 5 400-0678
Rear AC panel complete set
Rear DC panel complete set
12 to 18
400-0679
400-0680
Qtfgtkpi"Eqfg"
CD600 Plus
A
85 – 264 Vac/50-60 Hz
D
20 – 30 Vdc
Typical CD600 Plus
