The majority of the sources and destinations require no explanation, though the following clarifications may be helpful:
- PGM monitor signals (and their downmixes) are taken pre-tone, pre-talkback.
- PGM and ASG ‘bus’ (as opposed to ‘output’) signals provide a raw, pre-processing feed from the bus.
‰ Turn the Scroller to select the required entry in the Source Group list and press the Scroller (or the its right button)
to confirm the Source Group selection. The cursor will move to the Source list for that Source Group.
‰ Turn the Scroller to select the required Source within the Source Group list and press the Scroller to confirm the
Source selection.
‰ Press the Scroller’s right button to move to the next list.
The next list displays "4E4AB8=0B8>=, along with any currently assigned destinations.
‰ Select "4E4AB8=0B8>= and press the Scroller. "4E4AB8=0B8>= will turn yellow and the cursor will
move to the Destination Group list.
‰ Turn the Scroller to select the required entry in the Destination Group list and press the Scroller to confirm the
Destination Group selection. The cursor will move to the Destination list.
‰ Turn the Scroller to select the required Destination within the Destination Group list and press the Scroller to
confirm the Destination selection.
‰ Confirm the new route, by pressing the '( button.
Routing operations are described in more detail in the Operator’s Manual.
Page 4-18 | Section 4: Configuration C10 HD Installation Guide
