C10 HD Installation Guide Section 4: Configuration | Page 4-33
'($ )$ # -#", !'
The Eyeconix images which can be displayed on the Channel Information Display are loaded onto the internal SBC Linux
server disks via an external computer, connected either locally or over the IP network:
Please see the Install Guide for information regarding networking the console’s SBC server.
‰ Ensure that the external computer has access to the folders exported by the C10 system.
‰ Login to the console (the username is sbc and the password is initially set to sbc123).
‰ Locate the Eyeconix folder on the console hard drive and copy the images into it.
Note that .jpg and .bmp file types can all be used with the Eyeconix system, and that images are automatically resized.
Filenames are restricted to 14 characters in length (not including the 7 characters added by the console) – files with
longer names will be ignored.
B: Console Configuration
