Solid State Logic C10 HD User Manual

$!
Parameter Condition Value Unit Notes
Height 7 U
665 mm
Width 19 in
Case only without rack ears 449 mm
Depth 344 mm Excludes connectors/cables
Weight (†) 17 – 21 kg Depending on I/O fitted
Heat Dissipation 5 Mic cards 500 W Maximum
1 Mic, 2 analogue, 1 digital card 350 W Typical
Voltage Range 100 – 240 V ±10%, AC only
Current Maximum over voltage range 5.6 – 2.3 A
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Noise Front 45 – 55 NR Variable speed fans
Rear 45 – 60 NR
Connectors Power in 1 and 2 IEC male
Network RJ45 100 baseT (Unused)
Sync out BNC 75Ω (Wordclock)
Madi 1–4 Duplex LC fibre
GPI Input 25-way D-type male
GPI Output 25-way D-type female
† RIO units must be supported on rack shelves. Do not rely on the rack ears alone.
Page 6-2 | Section 6: Appendices C10 HD Installation Manual
A: Specifications
