Solid State Logic C10 HD User Manual

1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
"  (&! "  $"! &$!  " !'&
RJ45 Plug RJ45 Plug
9,7:2@0!@?;@?H
Location: Alpha-Link 8-RMP rear panel
Connector Type: 25-way D-type female
Cct Hot Cold Screen Notes
1 24 12 25 Pin 13 unused
2 10 23 11
3 21 9 22
4 7 20 8
5 18 6 19
6 4 17 5
7 15 3 16
8 1 14 2
"  $"
4.=:;3:909;@?
Location: Alpha-Link 8-RMP Rear panel
Connector Type: XLR 3-pin female
Pin Description Notes:
1 Ground
2 + signal
3 – signal
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
MIC/LINE IN 1 MIC/LINE IN 2 MIC/LINE IN 3 MIC/LINE IN 4 MIC/LINE IN 5 MIC/LINE IN 6 MIC/LINE IN 7 MIC/LINE IN 8
LINE OUT 1 – 8
CONNECT TO
ALPHA-LINK
PORT NUMBER
POWER
Page 6-12 | Section 6: Appendices C10 HD Installation Manual
C: Connector Pinouts
Pin Cable Pair Pin
1 1 + 4
2 1 – 5
5 2 + 2
4 2 – 1
8 3 + 6
7 3 – 3
6 4 + 8
3 4 – 7
* Only required for Alpha-Link Live units. Alpha-Link LIVE-R is able to use standard Ethernet pin-pin cables.
