Front Panel Menu
Page 5-56 | Section 5: System Administration C10 HD Installation Manual
' '()
If the faders become miscalibrated due to temperature variations or physical knocks since the front panel was last powered
up, they can be recalibrated by pressing this button.
A
ll of the faders will close and an <5AC pop-up will appear in the centre of the Touchscreen:
Note that when the faders close, the audio is not changed in any way – it is completely safe to do a fader reset, even
while On-Air!
The system uses the fully closed position as a mechanical reference for calibrating the faders.
‰ Manually close any faders that were not moved to this position — perhaps their motion was blocked by a book or
tape.
‰ Touch ?>C9>D5 to activate the recalibration process, which takes a couple of seconds.
‰ Once the reset is completed, faders are returned to their correct mixing positions and you may continue working as
normal.
Note that this function also re-initialises all the front panel controls, and could therefore be used after clearing a front
panel lockup if you are suspicious that some of the controls have been knocked out of position (note that a Layer change
will also refresh the front panel).
