C10 HD Installation Manual Section 5: System Administration | Page 5-51
'$#) %#! "#*
These options within the Maintenance pages allow a number of facilities to be configured that relate to the
operating surface of the console.
The submenus are: (3A922<5, (5CC9>7B, C85A>5C%(5CD@, and 145A'5B5C.
(
'!
This pop-up allows the electronic scribble strips (found above every fader) to be configured. The pop-up shows two
options:
The 561D<C81>>5<#1=5 option allows you to enter a default name for the scribble strips when no user name has
been entered (the console will automatically add the appropriate fader number to the end of this). If you leave this box
blank, then the input name of the channel source will be copied directly to the scribble strip – ideal for channels fed from
a router as its name labels may then be dynamically imported to the channel TFT screen and the scribble display
simultaneously!
The (8?F145ABL4 option allows the momentary display of the fader gain in the scribble window when the fader is
adjusted.
())#(
This pop-up includes three small faders which control the brightness of (from left to right) the console’s screens, scribble
strip, and LEDs.
‰ To adjust each fader, simply drag it on the Touchscreen.
‰ To set the ‘2nd function’ time delay for all press-and-hold functions (such as resetting the EQ section), touch the
%A5BB?<45<1H2?G, type a new time and press >C5A.
‰ To switch the Centre Section softkeys between Banked and Unbanked modes, touch the box by the 1>;B?6(?6C
5HB label. The box is ticked when banks are active.
