C10 HD Installation Manual Section 5: System Administration | Page 5-9
)-) ! $%')$#(
The only text files that should be edited without SSL supervision are those related to User Mode and GPIO assignments
and DAW displays. Each text file includes its own set of instructions.The files which may be required are as follows (all
within the #(GGGG directory, where GGGGG is the console serial number):
9<51>4!?31C9?> 5B3A9@C9?>
U
tility Tiles-> Tile Functions 0 Utility Modes assignments
Function Lists -> Functions.lst The full list of console functions, including proper names as well as value ranges and
offsets.
Important note: This file includes functions that are suitable for inclusion in the channel and Centre Section softkey
Functions lists (as well as, potentially, the GPIO list), but also a number of functions that should not be assigned to
softkeys. Therefore, take care not to allow softkey access to unsuitable functions.
Function Lists -> gpio.lst GPIO functions included in the GPIO functions display.
sysfiles-> DAWfuncs DAW displays assignments (See Appendix F for details).
config_x.0-> The console’s entire configuration is loaded in config folders, and the highest numbered
folder (indicated here with an x) contains the configuration included in the most recent
software update. This folder can be used for copying any files which are missing or
which have been irretrievably edited. It is essential that the files contained are not
edited while still within the config folder.
')# $!'(
Folders can most easily be added to the Channel and Centre Section softkey Functions displays by duplicating an already
existing file to a new location using the 9<5 / ?@H function, renaming it and editing its contents.
