Hole 9mm for

M8 Fixing bolts

8ch

16ch

24ch

32ch

40ch

Front

Trim

Position of console bay

285

257 28 257

Position of console bay

285

122

302

576

861

1,146

1,431

1,716

Length L

100

538

302

Drilling Template For Mounting Bolts

Table Positioning

Table Height

Clearance for

Cables

Page 6-18 | Section 6: Appendices C10 HD Installation Manual

F: Table Mounting the Console
