† Alpha-Link units must be supported on rack shelves. Do not rely on the rack ears alone.
7;3,496$"
Parameter Condition Value Unit Notes
Height 2 U
89 mm
Width 19 in
Case only without rack ears 449 mm
Depth 300 mm Excludes connectors/cables
Weight (†) 6.0 kg
Heat Dissipation 50 W Shared between two PSUs
Voltage Range 100 – 240 V ±10%, 50/60Hz AC only
Current Maximum over voltage range 0.6 – 0.3 A Maximum
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Connectors Power in 1 and 2 IEC male
Microphone Inputs XLR 3-pin female
Line level Output 25-way D-type female
Remote control RJ45 socket
C10 HD Installation Manual Section 6: Appendices | Page 6-1
A: Specifications
7;3,4964A04A0$
Parameter Condition Value Unit Notes
Height 2 U
89 mm
Width 19 in
Case only without rack ears 449 mm
Depth 300 mm Excludes connectors/cables
Weight (†) 6.0 kg
Heat Dissipation 50 W Shared between two PSUs
Voltage Range 100 – 240 V ±10%, 50/60Hz AC only
Current Maximum over voltage range 0.6 – 0.3 A Maximum
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Connectors Power in 1 and 2 IEC male
Analogue Inputs 25-way D-type female
Analogue Outputs 25-way D-type female
Digital input/output 25-way D-type female
Video In BNC 75Ω
Word Clock Out BNC 75Ω
MADI input/output Duplex SC fibre socket
Remote control RJ45 socket
