Parameter Condition Value Unit Notes
Height To top of meter trim 977 mm
Height adjustment -0 +10 mm
Width 24 channel console 1146 mm
Additional 8 channel bay +285 mm Add or subtract
Contoured side trims +60 mm
30mm each side
Depth 768 mm + additional 15mm for heatsinks
Weight 8 channel 35 kg Approximately, without legs
16 channel 65 kg Approximately, including legs
24 channel 83 kg ““
32 channel 97 kg ““
40 channel 113 kg ““
Heat Dissipation 8 channel 125* W Worst case, single CPU
16 channel 225 (275) W Single CPU (Redundant CPU)
24 channel 250 (300) W ““
32 channel 280 (330) W ““
40 channel 315 (365) W ““
Voltage Range 100 – 240 V ±10%, AC only
Current 8ch max. over voltage range 1.0 – 0.5 A
16ch max. over voltage range 2.3 – 1.0 A
24ch max. over voltage range 3.0 – 1.2 A
32ch max. over voltage range 3.1 – 1.3 A
40ch max. over voltage range 3.4 – 1.5 A
Power Factor 0.95 Approximately
Fusing No user-accessible fuses
Noise Fanless
Connectors Power in Main/Backup IEC 3-pin male 10A
Network TCP/IP RJ45 100 baseT
MADI fibre Duplex LC multimode (not APC)
GPI input 25-way D-type male
GPI output 25-way D-type female
Headphone input XLR 3-way female
Talkback audio output XLR 3-way male
"" %
%"&! %
* CPU redundancy is not available on the 8-channel frame.
Page 6-iv | Section 6: Appendices C10 HD Installation Manual
A: Specifications
