9,7:2@09;@?!@?;@?HHH
Location: Alpha-Link rear panel
Connector Type: 25-way D-type female
Cct Hot Cold Screen Notes
1 24 12 25 Pin 13 unused
2 10 23 11
3 21 9 22
4 7 20 8
5 18 6 19
6 4 17 5
7 15 3 16
8 1 14 2
%'9;@?>!@?;@?>HHH
Location: Alpha-Link Rear Panel
Connector Type: 25-way D-type female
Pin Description Notes:
1 Out channels 7/8 + Outputs
14 Out channels 7/8 -
2 Ground
15 Out channels 5/6 +
3 Out channels 5/6 -
16 Ground
4 Out channels 3/4 +
17 Out channels 3/4 -
5 Ground
18 Out channels 1/2 +
6 Out channels 1/2 -
19 Ground
7 In channels 7/8 + Inputs
20 In channels 7/8 -
8 Ground
21 In channels 5/6 +
9 In channels 5/6 -
22 Ground
10 In channels 3/4 +
23 In channels 3/4 -
11 Ground
24 In channels 1/2 +
12 In channels 1/2 -
25 Ground
13 n/c
WORD
CLOCK
OUT
R
EMOTE
RMP 1
POWER
WORD CLOCK
VIDEO IN
USBAES/EBU - CAES/EBU - BAES/EBU - AOUT 1 IN 1 OUT 2 IN 2
MADI
A
NALOGUE 17 – 24ANALOGUE 9 – 16ANALOGUE 1 – 8
OUT 9 – 16
IN 9 – 16
OUT 17 – 24
IN 17 – 24
OUT 1 – 8
IN 1 – 8
RMP 2
RMP 3
C10 HD Installation Manual Section 6: Appendices | Page 6-11
C: Connector Pinouts
