The final procedures for Preset-level user configuration are the creating of Channel Presets and Control Linking. These
allow the settings on any section of the channel to be stored and recalled. They are particularly important to Preset-level
users as they include a number of important parameters which are locked out to them.
Presets are recalled using the Master Control Strip # / $&'( function, and any Preset can be recalled to any
relevant channel. Control Linking allows the same parameters as are available in Presets to be associated with a specific
input source, enabling channels to be automatically configured according to the input that is routed to them.
If you are new to operating a C10, then Sections 2 and 3 will provide you with all of the channel configuration guidance
you may need.
$&
'('
To create a Preset:
‰ Configure a channel to reflect the Preset you wish to create.
‰ Press the !' ( ) button in the User Toolbox, followed by the $&'(' ( ) button in the sub-menu
that appears to open the $@4A4B 81@0@F >03'0D4 display in the Touchscreen:
‰ Highlight all of the parameters/sections of the channel that you would like to store in the right-hand list (they will turn
grey-blue). You can use the '4;42B;; and )=A4;42B;; boxes to highlight all or none of the parameters respectively.
‰ Press '0D4$@4A4B, name the new preset using the pop-up keyboard and press #.
Page 4-34 | Section 4: Configuration C10 HD Installation Guide
B: Console Configuration
