The following pages provide detailed guides to assist during the removal of console sub-assemblies as may be required for
servicing or maintenance.
The following tools are supplied with the console trim kit:
2mm hex driver – Used to remove the fixing screws for the fader and control tiles.
Posidrive no.1 screwdriver Used for other M3 fixing screws.
Module puller – Custom M4 screw used to lift the edges of the control tiles to aid removal.
6mm Hex key – Suitable for the leg fixing bolts.
In addition to the above a small flat-bladed screwdriver will be required to remove the locking screws on D-type
connectors.
%&+ !$&!
• 7B,D> use the software ‘Shutdown’ process before switching off power to the console.
Using the touchscreen menus: press ‘Studio’ (spanner icon) –> ‘System’ (gear wheels icon) –> ‘Shutdown’ (Console with cross
icon) then select the ‘Shutdown’ button from the four options. Wait until the screens become black before switching off the
console power.
• 7B,D> switch off the mains power to both inputs AND remove both of the input power IEC connectors
before removing any panels or trim.
• Component surfaces inside may be hot immediately after switching off.
• There may be sharp edges exposed inside the console frame.
• To help protect panels from becoming scratched after removal, have a soft cloth or sheet of antistatic foam to hand
before removing them from the frame.
• A plastic cup is a useful place to store fixing screws after their removal; it prevents them from falling inside the
frame and makes them easy to find during reassembly.
C10 HD Installation Manual Section 7: Service Information | Page 7-iii
