Main I/O Panel Power Inputs 1 & 2
Main I/O Panel
Backup I/O Panel
Power Inputs 1 & 2
Backup I/O Panel
Channels 1 –8
Leg Attachment
Inserts
(M8 – 4 per bay)
Frames viewed from below. Legs not shown for clarity.
Channels 17 – 24Channels 25 – 32
(32 ch frame only)
Channels 9 – 16
(16 ch frame only)
Centre Section
Channels 1 –8Channels 9 – 16Centre Section
