The RMP is an 8-channel microphone amplifier in a 2U high 300mm deep 19” rack unit. It features dual power supplies for
on-air reliability. Switchable phantom power is available on each input.
The 8-RMPs connect directly to an Alpha-Link LIVE-R unit, not to the console surface. Up to three units can be connected
to each Alpha-Link LIVE-R.
& %# $
Analogue outputs from the 8-RMP are at line level and should be connected to an Alpha-Link LIVE-R using 8-circuit
balanced audio cable.
Remote control information is provided by a separate RJ45 data cable.* Pairs of audio-plus-control cables can be ordered
from SSL in lengths of 1m, 5m, 10m and 25m. Cable pinouts are listed in the appendices. The maximum recommended
cable length between each Alpha-link 8-RMP and an Alpha-Link LIVE-R is 50m.
% # $&#*
See Section 6-12 for the connector pinouts.
*Pinout of the data cable will differ depending on whether Alpha-Link Live or Alpha-Link LIVE-R is being used. Refer to previous
section for further information.
'2+ 433+)947 +8)7/59/43
Mic/Line In XLR3 F Microphone input. Pin 2 +ve. Switchable phantom power.
Line Out D25 F 8 channel balanced audio outputs, line level.
Remote RJ45 Control data connection to Alpha-Link LIVE-R.*
>89+242543+398
389'11'9/43'3:'1 +)9/437+5'7'9/43? '-+
