Field Setting
User - SIP
Username/Extension Must contain information used for SIP registration etc.
E.g. the "user" in a SIP URI.
Domain (Optional) Enter the domain part of a SIP URI.
E.g. example.org in
John Doe<sip:1234@example.org>
Note: If not configured, the default domain entered under
SIP configuration will be used.
Displayname (Optional) Enter the name of the user (e.g. caller ID).
E.g. John Doe in
John Doe<sip:1234@example.org>
Note: If Cisco Unified CM(Advanced Features) License
is loaded, the Cisco Unified CM will not use this, but it
may ease the administration of users within the Spec-
tralink IP-DECT Server.
Authentication user (Optional) Enter the user ID of the end user.
E.g. JohnDoe or 5208.
Note: The user name will override the Default User field
under SIP Configuration.
Priority:
1. Authentication user set for individual users
2. Authentication user set in server SIP settings
3. User name set for individual users
Authentication password
(Optional)
Enter the digest credential of the end user.
Note: The password will override the Default Password
field under SIP Configuration.
User - Features
Call forward unconditional
(Optional)
A Call Forward Unconditional (an extension to forward
calls to) can be added/removed via the web based Admin-
istration Page.
