Field
Require encryption (Optional) If enabled, the connection between the media resource
and the Spectralink IP-DECT Server is required to be
encrypted.
Note: Enabling this, will only allow media resources with
firmware PCS17Fa or newer to connect.
If not enabled, the connection will be encrypted if the
media resource supports encryption.
Wireless Server Configuration - Base stations (Not relevant to the Spectralink IP-DECT
Server 200.
Allow new (Optional) If enabled, new base stations are allowed to connect to
the server.
Add new as active (Optional) If enabled, new base stations will become active when
added. Otherwise, they must be activated manually under
Administration > Base Station >Base Station page.
Require encryption (Optional) If enabled, the connection between the base station and
the Spectralink IP-DECT Server is required to be encryp-
ted.
Note: Enabling this, will only allow base stations with firm-
ware PCS17Fa or newer to connect.
If not enabled, the connection will be encrypted if the base
station supports encryption.
RFP port range start Port range start for RFP local RTP ports.
Default value: 57000
Note: It is possible to change the value in case of con-
flicting ports.
Multicast signaling (Optional) Multicast signaling is optimal when having many base sta-
tions and is required with more than 256 base stations con-
nected.
If enabled, this will impose multicast support for the net-
work.
For more information, see "Using Multicast" on page126.
Multicast address (Optional) Multicast address used for signaling.
Default value: 239.255.1.11
Please refer to RFC2365 and RFC4291 for details.
