22.5 Output JOB Data
Measured data, occupied data, known point data, note and coordinates data existed in all JOBs
could be outputted to PC via serial port.
NOTE:
 The software STONEX exchange is available in your CD-ROM or download from
www.stonexpositioning.com.
 Be sure the communication port setting of instrument and PC is the same, see “§3.8.3.
Communication Port Setting”, you can select MEM/1.JOB/5.Com setting to set the
communication parameters also.
【Procedure of download】
1. Select [MEM] in the status mode to enter into memory
management.
2. Select “1. JOB” to enter JOB management.
3. Connect your instrument and computer via
communication cable (standard component).
4. Select “4. Download” to enter into com output mode
and all JOBs display.
5. Select the JOB to be output.
6. Press key {ENT} to start to send out via RS-232C port, it
will back to JOB list mode after finishing.
More details see the Help file of STONEX Exchange, see
chapter “2.1 Data transfer via RS-232C port”.
Com output
Sending 0
JOB deletion P1
JOBA
JOB1
JOB-Paul01
MYJOB000000
JOB-B
JOB01
JOB-C
15
56
20
50
45
2
0
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
JOB
1.JOB select
2.JOB rename
3.JOB delete
4.Download
5.Com setting
6.File Copy
