Stonex R2 PLUS Total Station - User Manual 90
20.6 Road Stake Out
1. Press F2: [MENU] on P2 of the basic measurement mode,
on the page 3 select 1.Road Calculation enter road menu.
2. Select 2.Road Setout to road setout menu.
At road setout menu select 1.Occ.Orientation to set the
station and backsight.
3. Select 2.RoadSetout to stake out road, the first center
station of road will display.
Here:
PT#: Station serial number
Code: Station mileage, “C” means center station, “R” means
right station, “L” means left station.
Press F1: [READ] key to open the station list.
Press F2: [PREV] key to display previous station..
Press F2: [NEXT] key to display next station.
4. Press F4: [ENT] to enter coordinate staking out screen,
see chapter “7.2 Coordinates Stake out Measurement” to
do that.
