Stonex R2 PLUS Total Station - User Manual 79
20.2 Input Road Horizontal Elements
Three types elements can be input, including line, curve and spiral.
20.2.1 Input Line Element
1. Make sure the instrument is in horizontal elements
editing menu, press F2 to display line element inputting
menu.
Input the line length and azimuth in the Dist and Azimuth
filed. Press F4:[ENT] key to confirm.
NOTE:
You can press F3:[ENDP] to enter the end point inputting
menu.
Input the end point coordinate directly, or press F1:[READ]
to recall from memory.
Press F3:[LINE] to back to the LENGTH menu
Press F4:[ENT] to confirm, you will see the line element in
the list menu.
Here EndPile means the end station of this element.
20.2.2 Input Circle Element
1. Make sure the instrument is in horizontal elements
editing menu, press F3 to display curve element inputting
menu.
Input the curve parameters, including length [Dist], radius
[Rad], azimuth [Azimuth] and turn [Turn].
2. Press F4: [ENT] key to confirm, back to the horizontal
elements menu.
Here EndPile means the end station of this element.
Line Input/END POINT
Pt# A
N 100m
E 0.000m
Z 0.000m
READ LEN ENT
Type EndPile
Line 100.000
DEL LINE CIR CURV
Line Input/LENGTH
Dist 100m
Azimuth 0°00′00″
ENDP ENT
CIRCLE INPUT
Dist 100.000m
Rad 100.000m
Azimuth 0°00′00″
Turn RIGHT
ENT
Type EndPile
Line 100.000
Circle 200.000
DEL LINE CIR CURV
