Stonex R2 PLUS Total Station - User Manual 89
20.5 Road Staking Out Data View
After design and calculate the road, all the staking points can be view.
1. Press F2: [MENU] on P2 of the basic measurement mode,
on the page 3 select 1.Road Calculation enter road menu.
2. Select 3.Road Setout to road setout menu.
3. Select 3.Road data view to view the staking station
data, the station list will display.
Here:
STAKE: Center station serial number
RSTAKE: Right station serial number
LSTAKE: Left station serial number
Press F1: [ ↑↓.P] key to change the function of ▲ and ▼
keys, if it is light, press ▲ or▼ to move cursor between
adjacent points. If it is backlight display, press▲ or ▼ key
to move cursor to display adjacent pages.
Press F2: [TOP] key to move cursor to first station.
Press F3: [LAST] key to move cursor to last station
Press F4: [SRCH] key to enter the serial number (PT#) to
look for the station.
4. Press F4: [ENT] to display the coordinate of selected
station.
PT#: Station serial number
Code: Station mileage, “C” means center station, “R” means
right station, “L” means left station.
Press F1: [NEXT] key to display next station.
Press F2: [PREV] key to display previous station.
To Next Page
