Stonex R2 PLUS Total Station - User Manual 62
13.2 Point Projection
The baseline must be defined before performing point projection.
【Procedure of point projection】
1. Select “3. Point projection” after finishing defining
baseline.
2. Input the point coordinate.
Press F2: [MEAS] to measure the point to project.
When recording the data as a known point, press key
{Func}, and press F2: [REC] on P2. Record method, see Ҥ
23.1 Input Known Point Coordinate by Keys”.
3. Press F4: [OK] to calculate Length, Offset and dVD will
display.
Length: Distance along the baseline from 1
st
point to 2
nd
point (X direction).
Offset: Distance from point to project to the position at
which a line extending from point of project intersects
the baseline at right angles (Y direction)
dVD: Elevation between the baseline and the projected
point.
Press F1: [NEZ] to display switching between coordinate and distance data.
Press F2: [REC] to record the coordinate as a known data.
Press F4: [S-O] to switch to stake out measurement of the projected point. See “6 Stake out
measurement”.
Press key {ESC} to continue point projection of a new point.
