Stonex R2 PLUS Total Station - User Manual 45
8.2 Area Calculation by Reading Existed Coordinates
【Procedure of area calculation】
1. Select F2: [MENU]/ 3. Area /2.Area.
2. Press F1: [READ] to display existed coordinates data
list.
3. Pt#: Known point data saved in the active JOB or in the
coordinate search JOB.
Occ./Coord: Coordinate data saved in the active JOB or
in the coordinate search JOB.
4. Select the first point in the list and press key {ENT} to
set.
The selected point is set as “Pt-01”.
5. Repeat steps 2 and 4 till all points are selected.
Make sure read the points clockwise or anticlockwise.
6. Press F2: [CALC], and the calculated area will display.
Press F4: [OK] to escape.
