Stonex R2 PLUS Total Station - User Manual 31
5. Distance Measurement
Please set the following items before distance measurement:
● Measurement condition (See §3.8.1 Measure Condition Setting)
● EDM (See §3.8.6 EDM setting)
【Procedure of distance measurement】
1. Aim at the target, press F3: [SHV2], the display mode
of basic measurement will change to SD/HD/VD mode, and
then press F1:[DIST] to start measure distance.
2. The symbol “*” moves continually when measuring
distance. Distance measuring mode, prism const and ppm
value are also presented.
3. Press F4: [STOP] to finish measurement. The “SD”,”HD”,
and “VD” will display as shown left.
4. Press F3: [SHV2], SD/HD/VD and SD/VA/HA are displayed
alternatively.
Dist
Fine
ppm 0
-----※ STOP
Meas PC 0
ppm 0
SD 10.329m
HD 7.009m
VD 7.586m P1
DIST S H V 1 SHV2 0SET
Meas PC 0
ppm 0
SD
HD II
VD P1
DIST S H V 1 SHV2 0SET
Meas PC 0
ppm 0
SD 10.329m
HD 7.009m
VD 7.586m P1
DIST S H V 1 SHV2 0SET
