Stonex R2 PLUS Total Station - User Manual 87
6. Press [ESC] back to road calculation menu.
20.4.2 Additional Station Setting
Some special stations can be calculated and stake out, the setting procedures are same with road
width element inputting, but their result are different; for road width element, the inputted
parameters are available from setting station to next element, but for additional station setting,
the inputted parameters are available only for setting station.
1. Make sure the instrument is in Road Define menu, select
3.Road Calculation
2. Press F2:[PEG] to enter additional station setting menu.
Press F1:[FIST] key, the cursor will move to the first
element.
Press F2:[LAST] key, the cursor will move to the last
element.
Press F3:[Del] key to delete the selected element.
Press F4:[ADD] key to add a new vertical element.
3. Press F4:[ADD] to enter road wide inputting menu.
4. Input the parameters of road width.
STATION: the road will take this width begin from this
point to next road width element
Lwide: left width
Rwide: right width
Press F4: [ENT] key to confirm.
RoadCal/Calc
STATION:0.000
SPAC 0.000 m
WIDE PEG ENT
ENT
Road Define
1.Horizontal Curve
2.Vertical curve
3.Road Calculation
RoadCal/Calc
STATION:0.000
SPAC 0.000 m
WIDE PEG ENT
SPile LW
FIST LAST DEL ADD
Wide Input
STATION: 155.500
Lwide 10.000m
Rwide 10.000m
ENT
