STONEX R2 PLUS User Manual

Stonex R2 PLUS Total Station - User Manual 91
20.7 Road File Management
20.7.1 Select a Road File
All the elements you inputted and the staking data you calculated are recorded in the current
road file. You can select other file to define other road, normally one file includes one road.
NOTE:
◆ There are 10 road files in total, the factory default setting is “ROAD1”.
◆ The default names are “ROAD1”, “ROAD2”… “ROAD10”, you can rename them if necessary.
Procedures:
1. Press F2: [MENU] on P2 of the basic measurement mode,
on the page 3 select 1.Road Calculation enter road menu.
2. Select 1.Road file to road file management menu.
3. Select 1.Road File Select to display road file list, the
cursor will stay on current Job file.
4. Press ▼ or ▲ arrow key to move cursor, after reach to the
job you want to select, press [ENT] key to confirm. The
program will back to road file management menu
automatically.
Road Calculation
1.Road file
2.Input the parameter
3.Road Setout
Road file
1.Road File Select
2.Road File Rename
3.Road File Delete
4.Road Initialize
Road File Select P1
ROAD1 96
ROAD2 55
ROAD3 0
ROAD4 0
ROAD5 0
ROAD6 0
ROAD7 10
Road File Select P1
ROAD1 96
ROAD2 55
ROAD3 0
ROAD4 0
ROAD5 0
ROAD6 0
ROAD7 10
