Stonex R2 PLUS Total Station - User Manual 63
14. Stake out Line
Stake out line is used for stake out a required point at a designed distance from the base line and
for finding the distance from the baseline to a measured point.
14. 1 Define Baseline
【Procedure of defining baseline】
To perform stake out line, please define a baseline first. The baseline can be defined by inputting
coordinates of the two points.
1. Press F2: [MENU] on P2 of the basic measurement mode.
2. Turn to P2, select “4. Stake out line”.
3. Input the instrument occupied data, see Ҥ6.1 Input the
occupied point data”.
4. Select “2. Define baseline”, following operations see
“§13.1 Define baseline” procedures 5, 6 and 7.
To Next Page
