Stonex R2 PLUS Total Station - User Manual 95
21. Record
You can record measured data, occupied data and notes into the active JOB. The memory is 60000
points in total.
21.1 Record Occupied Data
You can input occupied data into the active JOB. The record items include: occupied coordinates,
point number, instrument height, code, user, date, time, weather, wind, temperature, air pressure
and ppm. If the current occupied data have not been recorded in the active JOB, the previous
occupied data will be used as the active one.
【Procedure of recording occupied data】
1. Press F4: [REC] on P3 in basic measurement mode to
enter into record mode. The active JOB will display.
2. Select “2. Occ. data” to set occupied station.
3. You can input the following items by hand: PT#,
instrument heigt(Inst.H), code, N0-E0-Z0, , user, date, time,
weather, wind, temperature, pressure, and ppm. Press key
“▲”/ “▼” to select item or press [FUNC] to turn page.
Press F1:[READ] to read coordinate from memory. See
“§6.1 Input the occupied point data”.
Press F2:[RES] to enter resection program and get the
station coordinate
Press F3:[REC] to record the station coordinate into
memory.
At the page 2 of station setting screen, press F1: [0PPM]
to set ppm value as 0 directly.
4. Press F1: [OK] to set the station coordinate.
5. Set the backsight information, and back to Rec menu.
