STONEX R2 PLUS User Manual

Stonex R2 PLUS Total Station - User Manual 96
NOTE
 If the inputted Pt# is the same as an existed one,
the instrument will display as shown left.
- Press F3: [NO] to re-input;
- Press F4: [YES] to overwrite;
- Press F1: [ADD] to save, and the original one will
not be deleted.
 The max length of Pt# is 14 characters.
 The instrument height range: -9999.999~9999.999.
 The max length of code and user is 16 characters.
 Date and time are not allowed to change here.
 Weather options: Fine, Cloudy, Flurry, Rain, Snow.
 Wind options: Calm, Gentle, Light, Strong, Gust.
 The temperature range: -30 ~ 60℃.
 The pressure range: 500 ~ 1400 hPa（mbar）/ 375 ~ 1050 mmHg /14.8～41.3 inch Hg/
7.3~20.3 Psi.
 The ppm range: -499 ~ 499 ppm.
Pt# J2
Inst.H 0.000m
Code ROAD
N0: 0.000
E0: 0.000
Z0: 0.000
Overwrite ?
ADD 0NO0 Y E S

STONEX R2 PLUS Specifications

General

Brand	STONEX
Model	R2 PLUS
Category	Measuring Instruments
Language	English
