12.1 Coordinate Resection
Between 2 and 5 known points can be measured by distance measurement and angle
measurement.
【Procedure of coordinate resection】
1. Select [MENU] at P2 of basic measurement mode and
then select “7. Resection”, or select [RES] at P3 directly.
2. Select “1.NEZ” and input known point data. After
inputting the data of the first known point, press F3: [NEXT]
to input the second point data.
3. After all known points data have been set, press F4:
[MEAS].
Press F1: [READ] to read existed coordinate data.
4. Sight the first known point and press F1: [DIST] to begin
measurement. If known points number is more than two,
F2: [ANG] will display, you can confirm the known point by
angle measurement.
5. Press F4: [YES] to use the measured data of the first
known point.
Press F3: [NO] to re-measure this point.
You can also input target height here.
To Next Page
