Stonex R2 PLUS Total Station - User Manual 75
6. According the S-O dHA angle to move the rod until the
telescope sight intersect the arc.
7. Repeat moving and measuring the rod until all the
stake data are accepted. Press F4: [ESC] to escape this
program.
19.2 Three Point Arc Staking Out
1. Press F2: [MENU] on P2 of the basic measurement
mode, select 7.Arc Staking out to enter arc staking out
menu, select 1.Occ.Orientation to set the station. And
then select 3.Three point arc to start three-point arc
staking out measurement.
2. Input the coordinate of arc start point.
Press F1[READ] to read the existed coordinate as stake
out coordinate
Press F4:[OK] to set the data.
3. Input the coordinate of arc end point.
Press F1[READ] to read the existed coordinate as stake
out coordinate
Press F4:[OK] to set the data.
To Next Page
