3.9.3 Communication Port Setting
Please set communication parameters before connecting your computer.
1. Press key {Cnfg} to enter into config mode.
2. Select “4.Com setting” to set the parameters of
communication port.
3. Change the settings if necessary. Press keys { }/ { } to
select items and press keys { } /{ } to set the options.
4. Press key {ESC} back to the previous mode.
Table 3-3 Option list of com setting
Item
Options
1.Baud rate
1200﹡/2400/4800/9600/19200/38400
2.Data bits
8bit﹡/ 7 bit
3.Parity
No﹡/ Even/ Odd
4.Stop bit
1bit﹡/ 2bit
5.Check sum
No﹡/ Yes
6.Xon/Xoff
No﹡/ Yes
7.Com mode
RS-232/B-TOOTH
NOTE:
Every first options with the symbol “﹡” are the factory setting.
Config
1.Meas condition
2.Inst config
3.Inst adjust
4.Com setting
5.Unit
6.Date & Time
7.Key Function
Com setting
1.Baud rate
2.Data bits
3.Parity
4.Stop bit
5.Check sum
6.Xon/Xoff
7.Comode :B-TOOTH
:1200
:8bit
:No
:1bit
:No
:No
