Stonex R2 PLUS Total Station - User Manual 56
6. Repeat procedures 4 and 5 of other points.
When the minimum quantity of measured data required
for the calculation is present, [CALC] will be displayed.
Press F1: [CALC] to calculate. Instrument occupied
coordinate and standard deviation are displayed.
Press F3: [NO] to re-measure the point.
7. Press F1: [NEXT] to add other known points.
Press F2:[DISP] to view the tolerance of measured known
points
Press F3: [REC] to record the calculated result.
Press F4: [OK] to finish coordinate resection.
The instrument occupied coordinate setting is finished.
8. In this <Set Azimuth> screen, aim the first point then
press F4: [YES] to set the first known point as backsight
point and azimuth, press F3: [NO] to back to measure
mode.
12.2 Elevation Resection
Only Z (elevation) of an instrument station is determined by this measurement. Between 1 and 5
known points can be measured by distance measurement only.
【Procedure of elevation resection】
1. Press F2: [MENU] on P2 of the basic measurement
mode and then select “7. Resection”, or press F4: [RES] at
P3 directly.
2. Select “2. Elevation” and input the known point.
