18. Repetition Angle Measurement
Repetition angle measurement can be done by horizontal
angle right measurement mode.
1. Press F2: [MENU] on P2 of the basic measurement mode.
2. Turn to P3, select “6.Repeat Measure”.
3. Press the F3: [Yes] key.
4. Collimate the target A and press the F1[0SET] key.
5. Press the F3: [Yes] key.
6. Collimate the target B using the horizontal clamp and
tangent screw.
Press the F4: [HOLD] key.
7. Recollimate the target A using the horizontal clamp and
tangent screw, and press the F3:[FREE] key.
8. Recollimate the target B using the horizontal clamp and
tangent screw, press the F4:[HOLD] key.
9. Repeat 7 to 8 to measure the desired number of repetition.
Menu P2
1.Point projection
2.Line stake out
3.Traverse
4.Inverse
5.Polarize
6.Repeat Measure
7.Arc staking out
Angle Remeasure
>OK?
---- ---- YES NO
Angle Remeasure [0]
Ht: 0°00′00″
Hm:
0SET MEAS FREE HOLD
Angle Remeasure [1]
Ht: 45°10′00″
Hm: 45°10′00″
0SET MEAS FREE HOLD
Angle Remeasure [1]
Ht: 45°10′00″
Hm: 45°10′00″
0SET MEAS FREE HOLD
Angle Remeasure [2]
Ht: 90°20′00″
Hm: 45°10′00″
0SET MEAS FREE HOLD
