Stonex R2 PLUS Total Station - User Manual 74
19.1 Two Point Arc Staking Out
1. Press F2: [MENU] on P2 of the basic measurement
mode, select 7.Arc Staking out to enter arc staking out
menu, select 1.Occ.Orientation to set the station. And
then select 2. 2pt+radius arc to start 2-point arc staking
out measurement.
2. Input the coordinate of arc start point.
Press F1[READ] to read the existed coordinate as stake
out coordinate
Press F4:[OK] to set the data.
3. Input the coordinate of arc end point.
Press F1[READ] to read the existed coordinate as stake
out coordinate
Press F4:[OK] to set the data.
4. Input the radius of arc, press F4:[OK] to set the data.
5. Press F1:[MEAS] to measure current rod, the staking
date will display.
Station - the station on the arc computed radially from
the current position of the prism.
Offset – offset distance from the current position to the
arc.
S-O dHA – offset angle from the current position to the
arc
Fill/Cut – Cut value indicate that the rod is higher than
the arc, fill indicates the it is lower
In/Out– This is the distance you need to move in out to
get to the arc.
