Stonex R2 PLUS Total Station - User Manual 42
7.3 REM Stake out Measurement
Perform this operation to find a point where a target cannot be directly installed, see “§11 REM”.
【Procedure of REM stake out measurement】
1. Set a target directly below or directly above the point to
be found, then use a measuring tape etc. to measure the
target height (height from the surveying point to the
target).
Press F1: [MENU] at P2 in the measure mode, then select
“2. Stake out”.
2. Select “2. S-Occ. Orientation”.
Input the occupied orientation data, see Ҥ6.1 Input the
occupied point data”.
3. Select “2. S-O data”, then select “1. Height”.
4. Input height from the surveying point to the position to
be stake out. Then press F4: [OK] to set the data.
5. Press F2: [REM] to begin REM stake out measurement.
Move telescope to find the point to be stake out.
: Move the telescope near the zenith
: Move the telescope near the nadir
Press key {ESC} back to stake out mode.
S-O
1. JOB select
2. Occ. Orientation
3. EDM
4. S-O data
Stake out
1.Height
2.Angle & Dist
3.Coord
S-O Ht 9.562
SD 10.251m
VA 79.6986gon
HA 249.0404gon I
MEAS R E M
S-O Ht
Ht. 2.000m
Tgt.H 0.000m
MOKS
