【Procedure of coordinate stake out measurement】
1. Press F1: [MENU] at P2 in the measure mode.
Select “2. Stake out”.
2. Select “1. Occ. Orientation”.
Input the occupied orientation data, see Ҥ6.1
Input the occupied point data”.
Then set the azimuth angle of the backsight point,
see “§6.2 Azimuth setting”.
3. Press Esc, then Select “2. S-O data”, then select
“3.Coord”.
4. Input the coordinates of the stake out point.
Press F1: [READ] to read the existed coordinates as
stake out coordinate.
Press F4: [OK] to set the data.
5. Press F1: [MEAS] begin coordinate stake out
measurement. Move the prism to find the point
to be stake out.
: Move the prism upward
: Move the prism downward
Press key {ESC} back to stake out mode.
Menu P1
1.Coordinate
2.Stake out
3.Area
4.Offset
5.MLM
6.REM
7.Resection
Stake out
1.Height
2.Angle & Dist
3.Coord
S-O Coord
Np: 157.000
Ep: 0.178
Zp: 0.000
Pt#
Tgt.H 1.500m
READ R E C MOKS
↓ -147.328m
0.000m
19.310m
S-O dHD ↑ -147.328
S-O dHA→ 146.7194go
VA 296.1184gon I
HA 249.0324gon
MEAS NEXT MOKS
