Stonex R2 PLUS Total Station - User Manual 108
22.7 Connect PC via USB port
R2 PLUS Series is equipped with USB port, you can connect it with PC for data transferring.
【Procedure of USB port connecting】
1. Select [MEM] in the status mode to enter into memory
management.
2. Select “5.USB” to enter USB port connecting screen.
3. Connect instrument and PC via USB cable, R1 will display
“U FUNCTION Stop Press ESC”.
It means the R1 is connected with PC already.
Press [ESC] to disconnect them, and the instrument bact
to previous menu.
For more information to see the Help file of STONEX
Exchane on chapter “2.2 Data transfer via USB slave port”.
U FUNCTION
Plug the USB
Exit Press ESC
U FUNCTION
Stop Press ESC
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
Memory
1.JOB
2.Known data
3.Code
4.Storage Media Select
5.USB
