Stonex R2 PLUS Total Station - User Manual 76
4.Input the coordinate of arc middle point.
Press F1[READ] to read the existed coordinate as stake out
coordinate
Press F4:[OK] to set the data.
5. Press F1:[MEAS] to measure current rod, the staking date
will display.
Station - the station on the arc computed radially from the
current position of the prism.
Offset – offset distance from the current position to the arc.
S-O dHA – offset angle from the current position to the arc
Fill/Cut – Cut value indicate that the rod is higher than the
arc, fill indicates the it is lower
In/Out(from Rod to A) – This is the distance you need to
move in out to get to the arc.
6. According the S-O dHA angle to move the rod until the
telescope sight intersect the arc.
7. Repeat moving and measuring the rod until all the stake
data are accepted. Press F4: [ESC] to escape this program.
