STONEX R2 PLUS User Manual

Stonex R2 PLUS Total Station - User Manual 127
Measurement time(Initial:2.5s)
Prism typical 1.0-1.5s,
Reflective sheet(RP60) typical 1.5s
Reflectorless typical 1.5-5s, max. 20s
Display resolution
Fine mode 0.1mm (0.001ft) /1mm (0.01ft)
Tracking mode 10mm(0.1ft)
Distance unit m/ft, selectable
Temperature unit ℃/℉, selectable
Pressure unit hPa/mmHg/inchHg, selectable
Temperature input range -30℃ to +60℃ (1℃ steps)
Pressure input range 510hPa to 1066hPa(1hPa setps)
Prism constant condition -99.9mm to +99.9mm
Refraction and earth curvature correction OFF/0.14/0.2, selectable
Reflecting prism constant correction -99.9mm to +99.9mm
Level vial sensitivity
Plate level 30″／2mm
Circular level 8′／2mm
Compensation Dual-axis
System Liquid type
Range ±3′
Optical plummet (Optional)
Accuracy ±0.8mm/1.5m
Image Erect
Magnification 3×
Focusing range 0.5ｍ～∝
Field of view 4°
Laser plummet*
2
Accuracy ±1mm/1.5m
Laser class Class 2/IEC60825-1
Laser wave length 635nm
Display
LCD 8 lines×24 characters (128x240 dots)
Memory
Internal memory 60000 points
External SD card 60000 points
