【Procedure of 3D coordinates measurement】
1. Aim at the target point.
2. Select “4. Measure” to start. The coordinate value of the
target is displayed.
3. Press F2: [TAGT] to re-input the occupied data if
necessary, see “§6.1 Input the occupied point data”. You
can press F4: [REC] to record the data.
4. Aim at the next target, press F2: [TAGT] to re-input the
target height if necessary, and press F1: [MEAS] to
continue. Follow this operation till all targets have
been measured.
5. Press key {ESC} back to the coordinate mode.
Coordinate
1. JOB select
2. Occ. Orientation
3. EDM
4. Measure
Coord Measure
N 1000.000
E 1000.000
Z 10.466
VA 132.3648gon II
HA 150.3536gon
MEAS T A G T R E C
