7 - 2 DS7708 2D Vertical Slot Scanner Product Reference Guide
Connecting an RS-232 Interface
There are two possible configurations for connecting to an RS-232 host. The DS7708 connects directly to the
host computer; and an auxiliary scanner can connect to the DS7708. Both configurations require a power
supply; 5 volt without an auxiliary scanner, and 12 volt with an auxiliary scanner.
Figure 7-1
RS-232 Connection - 5 Volt Power Supplied Externally
Host Port
5 Volt Power
Supply
Host
