Tektronix Keithley 4200A-SCS User Manual

Section 6: Using a Model 82 C-V System Model 4200A-SCS Prober and External Instrument Control
6-34 4200A-913-01 Rev. A December 2020
The analog filter, enabled with Filter590, can minimize the amount of noise that appears in the
readings. It does, however, increase the measurement time.
Reading_rate valid inputs
Reading rate
Nominal reading rate
(per second)
Readings
Display resolution
(digits)
1
75
C,G,V
3.5
2
18
C,G,V
4.5
3
10
C,G,V
4.5
4
1
C,G,V
4.5
Range590 valid range values
Range
100 kHz
1 MHz
1
2 pF / 2 µs
20 pF / 200 µs
2
20 pF / 20 µs
20 pF / 200 µs
3
200 pF / 200 µs
200 pF / 2 ms
4
2 nF / 2 ms
2 nF / 20 ms
If CabCompFile does not exist, or if there is no path specified (null string), the default compensation
parameters are used. When entering the path, be sure to use two \ characters to separate each
directory. For example, if your cable file is in:
C:\calfiles\82cal.dat
You would enter:
C:\\calfiles\\82cal.dat
If you are controlling a switch matrix to route signals using a connection UTM (for example,
“connect”), you do not need connect InputPin and OutputPin. Set these parameters to 0.
The return values from status can be:
• 0: OK.
• -10000 (INVAL_INST_ID): The specified instrument ID does not exist(INVAL_INST_ID): The
specified instrument ID does not exist
• -10020 (COMP_FILE_ACCESS_ERR): There was an error accessing the specified cable
compensation file
• -10021 (COMP_FILE_NOT_EXIST): The specified compensation file does not exist
• -10045 (KI82_NOT_IN_KCON): There is no CMTR defined in your system configuration
• -10023 (KI590_MEAS_ERROR): A measurement error occurred
• -10101 (ARRAY_SIZE_TOO_SMALL): The specified value for CHF_ArrSize,
G_or_R_ArrSize, or Time_ArrSize was too small for the number of steps in the sweep
• -10102 (ERROR_PARSING): There was an error parsing the response of the 590.
• -10104 (USER_CANCEL): The user canceled the correction procedure.
• -10090 (GPIB_ERROR_OCCURRED): A GPIB communications error occurred
• -10100 (INVAL_PARAM): An invalid input parameter is specified
