8.1.7. Summary of Quality Assurance Checks
The following items should be checked on a regularly scheduled basis to assure high
quality data from the M100E. See Table 8-3 for a summary of activities. Also the QA
Handbook should be checked for specific procedures.
Table 8-3: Activity Matrix
Characteristic Acceptance limits
Frequency and method
of measurement
Action if requirements
are not met
Shelter temperature Mean temperature
between 22
o
C and
28
o
C (72
o
and 82
o
F),
daily fluctuations not
greater than ±2
o
C
Check thermograph chart
weekly for variations
greater than ±2
o
C (4
o
F)
Mark strip chart for the
affected time period
Repair or adjust
temperature control
Sample introduction
system
No moisture, foreign
material, leaks,
obstructions; sample
line connected to
manifold
Weekly visual inspection Clean, repair, or replace
as needed
Recorder Adequate ink & paper
Legible ink traces
Correct chart speed
and range
Correct time
Weekly visual inspection Replenish ink and paper
supply
Adjust time to agree
with clock; note on chart
Analyzer operational
settings
TEST measurements
at nominal values
2. M100E in SAMPLE
mode
Weekly visual inspection Adjust or repair as
needed
Analyzer operational
check
Zero and span within
tolerance limits as
described in Subsec.
9.1.3 of Sec. 2.0.9
(Q.A. Handbook)
Level 1 zero/span every 2
weeks; Level 2 between
Level 1 checks at
frequency desired
analyzer by user
Find source of error and
repair
After corrective action,
re-calibrate analyzer
Precision check Assess precision as
described in Sec.
2.0.8 and Subsec.
3.4.3 (Ibid.)
Every 2 weeks, Subsec.
3.4.3 (Ibid.)
Calc, report precision,
Sec. 2.0.8 (Ibid.)
8.2. Level 1 Calibrations versus Level 2 Checks
Essential to quality assurance are scheduled checks for verifying the operational status of
the monitoring system. The operator should visit the site at least once each week. It is
recommended Level 1 zero and span check conducted on the analyzer every two weeks.
Level 2 zero and span checks should be conducted at a frequency desired by the user.
Definitions of these terms are given in Table 8-4.
