Model 100E Instruction Manual APPENDIX A-3: Warnings and Test Functions,
Revision B.3
045150110 Rev B.3 241
Table A-3: M100E Test Functions, Revision B.3
TEST FUNCTION MESSAGE TEXT DESCRIPTION
RANGE RANGE=500.0 PPB
3
D/A range in single or auto-range modes.
RANGE1 RANGE1=500.0 PPB
3
D/A #1 range in independent range mode.
RANGE2 RANGE2=500.0 PPB
3
D/A #2 range in independent range mode.
STABILITY STABIL=0.0 PPB
3
Concentration stability (standard deviation based on
setting of STABIL_FREQ and STABIL_SAMPLES).
RESPONSE
2
RSP=1.11(0.00) SEC Instrument response. Length of each signal processing
loop. Time in parenthesis is standard deviation.
VACUUM
5
VAC=9.1 IN-HG-A Vacuum pressure.
SAMPPRESS PRES=29.9 IN-HG-A Sample pressure.
SAMPFLOW SAMP FL=700 CC/M Sample flow rate.
PMTDET PMT=762.5 MV Raw PMT reading.
NORMPMTDET NORM PMT=742.9 MV PMT reading normalized for temperature, pressure,
auto-zero offset, but not range.
UVDET UV LAMP=3457.6 MV UV lamp reading.
LAMPRATIO LAMP RATIO=100.0 % UV lamp ratio of current reading divided by calibrated
reading.
STRAYLIGHT STR. LGT=0.1 PPB Stray light offset.
DARKPMT DRK PMT=19.6 MV PMT dark offset.
DARKLAMP DRK LMP=42.4 MV UV lamp dark offset.
SLOPE SLOPE=1.061 Slope for current range, computed during zero/span
calibration.
OFFSET OFFSET=250.0 MV Offset for current range, computed during zero/span
calibration.
HVPS HVPS=650 VOLTS High voltage power supply output.
RCELLDUTY RCELL ON=0.00 SEC Sample chamber temperature control duty cycle.
RCELLTEMP RCELL TEMP=52.1 C Sample chamber temperature.
BOXTEMP BOX TEMP=35.5 C Internal chassis temperature.
PMTTEMP PMT TEMP=7.0 C PMT temperature.
IZSDUTY IZS ON=0.00 SEC IZS temperature control duty cycle.
IZSTEMP IZS TEMP=52.2 C IZS temperature.
SO2 SO2=261.4 PPB SO
2
concentration for current range.
TESTCHAN TEST=3721.1 MV Value output to TEST_OUTPUT analog output, selected
with TEST_CHAN_ID variable.
CLOCKTIME TIME=10:38:27 Current instrument time of day clock.
1
The name is used to request a message via the RS-232 interface, as in “T BOXTEMP”.
2
Engineering software.
3
Current instrument units.
5
M100EH
