Model 100E Instruction Manual Getting Started
045150102 Rev XB1 27
Various rack mount kits are available for this analyzer. See Chapter 5 of this manual for
more information.
3.1.1. Electrical Connections:
CAUTION
Check the voltage and frequency label on the rear panel of the
instrument for compatibility with the local power.
Do not plug in the power cord if the voltage or
frequency is incorrect.
Power connection must have a functioning ground connection.
Do not defeat the ground wire on power plug.
Turn off analyzer power before disconnecting or
connecting eletrical subassemblies.
Do not operate with cover off.
Figure 3-2: Rear Panel Layout
