Table A-6: M100E iDAS Functions, Revision B.3
NAME DESCRIPTION UNITS
PMTDET PMT detector reading mV
UVDET UV lamp intensity reading mV
LAMPR UV lamp ratio of calibrated intensity %
DRKPMT PMT electrical offset mV
DARKUV UV lamp electrical offset mV
SLOPE1 SO
2
slope for range #1 —
SLOPE2 SO
2
slope for range #2 —
OFSET1 SO
2
offset for range #1 mV
OFSET2 SO
2
offset for range #2 mV
ZSCNC1 SO
2
concentration for range #1 during zero/span calibration,
just before computing new slope and offset
PPB
ZSCNC2 SO
2
concentration for range #2 during zero/span calibration,
just before computing new slope and offset
PPB
CONC1 SO
2
concentration for range #1 PPB
CONC2 SO
2
concentration for range #2 PPB
STABIL SO
2
concentration stability PPB
STRLGT Stray light reading PPB
RCTEMP Sample chamber temperature °C
IZSTMP
1
IZS temperature °C
PMTTMP PMT temperature °C
SMPFLW
1, 2
Sample flow cc/m
SMPPRS Sample pressure “Hg
VACUUM
2
Vacuum pressure “Hg
BOXTMP Internal box temperature °C
HVPS High voltage power supply output Volts
TEST8 Diagnostic test input (TEST_INPUT_8) mV
TEST11 Diagnostic test input (TEST_INPUT_11) mV
TEMP4 Diagnostic temperature input (TEMP_INPUT_4) °C
TEMP5 Diagnostic temperature input (TEMP_INPUT_5) °C
TEMP6 Diagnostic temperature input (TEMP_INPUT_6) °C
REFGND Ground reference (REF_GND) mV
RF4096 4096 mV reference (REF_4096_MV) mV
1
M100E.
2
M100EH.
